Hitachi Nozzles

Hitachi GXH-1, GXH-3
Part Number Description
630 128 4842 (#101) HA01 (for 0603) 0.7x0.4/Ø0.25
630 132 2322 (#111) PV01 (for 1005) 1.1x0.6/Ø0.38
630 132 9857 (#112) PV02 (for 1608) 1.7x0.9/Ø0.65
630 129 2892 (#104) HV03 (for 2012) Ø1.3/Ø0.9
630 129 2922 HA04 (for 3216) Ø1.8/Ø1.2
630 129 2939 (#108) HA05 Ø3.0/Ø2.0

Mirae MX-310, MX-240, MX-110, MPS-1010, MPS-1020, MPS-1025
Part Number Description
A (1005) 0.65/ 0.38
A+B (1005~1608) 1.0/ 0.5
B (1608) 1.2/ 0.65
B (1005~1608) 1.2/ 0.7 Diamond
C 2.0/ 1.0
D 3.0/ 2.0
E 6.0/ 4.5
SPECIAL Connector Nozzles


I-Pulse Nozzles

I-Pulse M1, M4
Part Number Description
M001 0.4mmx0.5mm
LG0-M7703-00 M002 0.95mmx0.65mm
LG0-M7703-00XS M002 (modified) Ø0.7/Ø0.45
LG0-M7705-00 M003 Ø1.3/Ø0.65
LG0-M7707-00 M004 Ø1.8/Ø1.2
LG0-M7709-00 M005 Ø3.0/Ø2.0
LG0-M770B-00 M006 Ø4.5/Ø3.5
LG0-M770D-00 M012 Ø2.0/Ø0.9
LG0-M770F-00 M013 Ø2.5/Ø1.2
M017 Ø4.0 PAD
LG0-M770K-00 M018 Ø6.0 PAD
M019 Ø8.0 PAD
M020 Ø10 PAD
LG0-M771K-00 M032 BUFFER NOZZLE
SPECIAL Connector Nozzles

I-Pulse M2
Part Number Description
LC1-M7701-00 N001
LC1-M7703-00 N002 0.95mmx0.65mm
LC1-M7703-00XS N002 (modified) Ø0.7/Ø0.45
LC1-M7705-00 N003 Ø1.3/Ø0.65
LC1-M7707-00 N004 Ø1.8/Ø1.2
LC1-M7709-00 N005 Ø3.0/Ø2.0
LC1-M770B-00 N006 Ø4.5/Ø3.5
LC1-M770D-00 N012 Melf
LC1-M770F-00 N013 Melf
LC1-M770H-00 N017 Ø4 PAD
LC1-M770K-00 N018 Ø6 PAD
LC1-M770M-00 N019 Ø8 PAD
LC1-M770P-00 N020 Ø10 PAD
LC1-M770S-00 N021
LC1-M770U-00 N022
LC1-M7714-00 N032 BUFFER NOZZLE
SPECIAL Connector Nozzles


Casio Nozzles

Casio YCM 3300
Part Number Description
S1 Ø0.7 (Ø0.38)
S2 Ø1.1 (Ø0.65)
S22 Ø1.2 (Ø0.9)
S31 Ø2.0 (Ø1.4)
NP1 Ø1.2 (Ø0.4) for 1005
NP2 Ø1.2 (Ø0.6) for 1608
P2 Ø1.2 (Ø0.4) for 1005-3216
P7 Ø3.0 (Ø1.0) for 3216-
No.04 Ø0.8 (Ø0.5) for 1608-3216
No.05 Ø1.2 (Ø0.9) for 2125-4532
No.06 Ø1.6 (Ø0.9) for 3216-5650 etc.
No.07 Ø3.0 (Ø2.3) for 5650-SOP

Casio YCM 7000-8800
Part Number Description
H03 (H3M) 0.3/0.5 (Ø0.25)
HS1 (H1M) Ø0.7 (Ø0.4)
H2 (H2M) Ø1.1 (Ø0.65)
H06 / T06 Ø1.56 (Ø1.0)
H7 / T7 Ø2.0 (Ø1.4)
H07 / T07 Ø3.0 (Ø2.3)
H21 / T21 Ø0.83 (Ø0.45) Melf
H22 / T22 Ø1.22 (Ø0.9) Melf
H23 / T23 Ø2.0 (Ø1.4) Melf
H24 / T24 Ø3.0 (Ø2.5) Melf
H31 / T31 Ø5.0 (Ø3.0)
H32 / T32 Ø6.0 (Ø4.0)
H33 / T33 Ø9.0 (Ø7.0)
H34 / T34 Ø11.0 (Ø9.0)
H35 / T35 Ø13.0 (Ø11.0)
H36 / T36 Ø18.0 (Ø16.0)
SPECIAL CNT NOZZLES
